fiber distribution box FTTH splitter distribution box 8 core wall mounted Fiber Optic Splitter Box

FOB Reference Price:Get Latest Price
US $5-10 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
YOUXIN
Model Number:
FTB-A8
Material:
ABS and PC ( Flame retardant)
Output Connector:
FC SC LC and etc.
Fiber Length:
1m.1.5m or customized
Splitter:
with splitter or without splitter
Splice:
mechanical splice and heat shrinking
SupplyAbility
SupplyAbility:
150000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
By Standard Export Carton
Port
Shanghai
Lead Time :
3-5 days
FTTH indoor termination box, 2 inlet and 8 oulet port,with 1x8 PLC splitter and 8pcs adapter
Features:
   1, 2 inlet&8 outlet
   2, Support SC, ST, FC, LC adaptor
   3, FTTx application
   4, multi-layer design
   5, wall or pole mount


Description

The UDM Splitter Terminal box is rugged, low cost, low
profile interconnection between central office and multi-dwelling units of FTTx application.

The design of UDM splitter terminal combines the functionality of a local convergence cabinet with UDM terminal.

Its multi-layer design allows installers to access only the components necessary for initial installation or subscriber turn-up. It can house the splitter and allows for pigtail splicing of distribution/drop cables as needed

1 8box

Parameter
Indoor or outdoor rated

· Available 1x4, 1x8 splitter as well as 2x4, 2x8 splitter

· Suitable for wall-mounting or pole mountingapplication.

· Max. up 8 pcs of FTTH drop cable or pigtails

· Suitable for wall-mounting or pole mounting application.

· 2 inlet ports and 8 outlet ports

Applications

FTTB, FTTH (FTTx)

Telecommunication Network

Local Area Network

ATM

CATV

HFC


1 (7).jpg1 (9).jpg
