Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: YOUXIN
  • Model Number: F11-60BV-CCS
  • Type: Coaxial, Coaxial
  • Number of Conductors: 1
  • Number Of Conductors: 1
  • Color: Black/White/Grey
  • Dielectric: SPE/FPE
  • Impedance: 75Ohms
  • PVC Degree: 65,68,70,75
  • Braiding: Al or Cu
  • Conductor: CCA/CCS/CU

Packaging & Delivery

Packaging Details By standard export carton.
Delivery Time 3-5 days according to the quantity.

F11 coaxial Cable, 1.63±0.01mmCCS(20%)+FPE7.11±0.05mm+ bonded AL foil+96/0.16AL wire+PVC10.03±0.2mm(70 °C), 305m wood drum.



Features
 Minimum Bend Radius: 10.2mm(0.253”)
 Maximum Pulling Tension: 10.2mm(0.253”)
 Capacitance: 15.3+/-0.1 pF/feet,(50+/-3 nF/km)
 Impedance: 75±2ohms
 Velocity of Propagation: 88% (Nominal)
 Maximum DC Loop Resistance:
1.61 ohms/1000 feet (2.52 ohms/km)
 Attenuation:@68 F(20°C)

Parameter
Frequency(MHz)
dB/100ft.(max.)
dB/100m(max.)
5
0.67
2.20
55
0.96
3.15
211
1.90
6.23
450
2.75
9.02
550
3.04
9.97
750
3.65
11.97
865
3.98
13.05
1000
4.35
14.27
