Optical receiver with for PHILIPS optical receiving module BGO807 and for PHILIPS amplifier module, 4 output ports, 87-862MHz, rated output level 96dBuV(input optical power -2dBm); return path frequency 5-65MHz, return path transmitter 1mW, diplex filter 65/87 (other freq. split is available), imperial F female port, FC/APC or SC/APC connector, waterproof housing, AC135~250V (power cord with EURO (2 pole with GND) or USA standard plug (3 pole)) or 35~90V.(SNMP management is optional)
(1 ) High quality for PHILIPS optical receiving module
(2) Eight-stage input optical power digital LED display
(3) Wide range of input optical power
(4) for PHILIPS Power Doublers output module
(5) Plug-in splitter(tap) in output and plug-in return path
(6) Local and remote powering
(7) Weatherproof and RF-screened die-cast housing
OR5400 Series Field Optical Receiver are the most common transmission equipment of CATV HFC, which mainly used in long distance optical fiber transmission for TV video signal, digital TV signal, telephone voice signal and data signal(compressed data).
Since our first CATV optical receiver come to market in 1995, we have done deep research on all kinds of technical performance parameters for more than 10years, accumulating a lot of experience in product development and engineer in practice. The internal circuit and external structure are much better and the performance is upgraded.
